Optical Plano Convex Lens Microscope Objective Lens For Magnifier / Projector

Basic Information
Place of Origin: Wuhan,China
Brand Name: Wuhan Siwer Optics
Minimum Order Quantity: 10 pieces
Price: 2-60USD/piece
Packaging Details: 1.Tissue paper. 2.Plastic foam packaging film. 3.Hard carton box with quakeproof filler
Delivery Time: 4-6 weeks
Payment Terms: T/T, Western Union
Supply Ability: 20000 pieces/month
Detail Information
Material: Optical Glass,BK7,SF,etc. Size Tolerance: +/-0.1mm
Chamfer: 0.2-0.5mm Surface Quality: 40/20
Surface Flatness: Lambda/4 In 25.4mm Centration: 3 Arc Min
Standard Coating: AR@400-700nm Size Range: 4-300mm
Usage: Optical System
High Light:

large plano convex lens

,

pcx lens


Product Description

Microscope objective lens Optical plano convex lens for Magnifier, projector,microscope,telescope

The majority of light microscopes have an objective lens of some kind, which includes both compound microscopes and stereo microscopes. These types of microscopes are also the same in that each type has an eyepiece or ocular lens.

The objective lens and the ocular or eyepiece lens are in combination responsible for magnification of the specimen being observed.

For example:
Total magnification = Objective magnification X ocular magnification
Therefore, for 10X objective and 10X ocular the total magnification = 10 X 10 = 100X
This means that the specimen being observed is now 100X it’s actual size.



The majority of compound microscopes come with interchangeable objective lenses, which have different magnification powers. This commonly includes 4x, 10x, 40x, and 100x objective lenses.



What is the Difference between Ocular and Objective lenses?

As previously mentioned, the ocular or eyepiece lens is located at the top of the eyepiece tube and is where you position your eye to observe the specimen. The ocular lens typically has a low magnification (10x) and works in combination with the objective lens to achieve a greater magnification power.

The objective lens is at the bottom of the eyepiece tube and is responsible for both total magnification of the specimen, as well as the resolving power of the microscope.

Optical Plano Convex Lens Microscope Objective Lens For Magnifier / Projector 0





Optical AR Coatings

a) Uncoated,The surface reflectivity of uncoated visible lenses(Refractive index=1.5) is about 4%.

Click on the link to see how to calculate reflectivity

b) AR/AR@400-700nm,Tavg>99.4%

c) AR/AR@450-650nm,Tavg>99.6%

d) AR/AR@400-1000nm,Tavg>98.5%

e) We can also customize high damage threshold antireflective coatings

Optical Plano Convex Lens Microscope Objective Lens For Magnifier / Projector 1








Production Line

Optical Plano Convex Lens Microscope Objective Lens For Magnifier / Projector 2




Optical Properties of Optical Lens

Material Optical glass
AR Coating Range 400-700nm or customized
Reflectance over
AR Coating Range @ 0° AOI

Ravg<0.5%

Diameter Tolerance +0.0/-0.1 mm
Thickness Tolerance ±0.1 mm
Focal Length Tolerance ±2%
Surface Quality 40/20 Scratch-Dig
Surface Flatness
(Plano Side)
λ/2 at 633nm
Spherical Surface Powerc
(Convex Side)
1.5λ at 633nm
Surface Irregularity
(Peak to Valley)
λ/2 at 633nm
Centration <3 arcmin
Clear Aperture >Ø10.16 mm (Ø1/2" Lenses)
>Ø20.32 mm (Ø1" Lenses)
Design Wavelength 546nm
