Round Achromatic Doublet Lens Optical Glass Doublets Cemented Lenses

Basic Information
Place of Origin: Wuhan,China
Brand Name: Wuhan Siwer Optics
Model Number: Achromatic lens
Minimum Order Quantity: 10 pieces
Price: 50-300USD/piece
Packaging Details: 1.Tissue paper. 2.Plastic foam packaging film. 3.Hard carton box with quakeproof filler
Delivery Time: 4-6 weeks
Payment Terms: T/T, Western Union
Supply Ability: 2000 pieces/month
Detail Information
Material: Optical Glass Size Tolerance: +/-0.1mm
Chamfer: 0.2-0.5mm Surface Quality: 40/20
Surface Flatness: Lambda/4 In 25.4mm Centration: 3 Arc Min
Standard Coating: AR@400-700nm Or Customized Size Range: 3-220mm
Usage: Optical System
High Light:

achromatic lens

,

achromatic cylindrical lens


Product Description

Acromatic Lens

  • Designed for 0° Angle of Incidence
  • Less Than 1.75% Reflectance Per Surface @ 400 - 700nm
  • VIS 0° and VIS-NIR Coated Achromats Also Available

Achromatic lenses are very common type of viewer lenses,they consist of two or more lense elements,which have been corrected for chromatic aberration with respect to two selected wavelengths,the elements must be fixed in relation to one another by either mounting or cement.
Achromatic lenses are designed to specifically function within the infrared,visible,or ultra-violet wavelength ranges,and they are not symmetric devices.
They must be installed with the correct front-to-back orientation (thicker element usually faces the eyes) if installed incorrectly.with the lens orientation installed backwards the result will be extensive distortion and aberration.
Optical glued lens are supplied coated or with a single layer anti-reflection coating suitable for the visible (400 - 700 nm) or the near infra-red (600 – 1200 nm).



Round Achromatic Doublet Lens Optical Glass Doublets Cemented Lenses 0



Optical AR Coatings

a) Uncoated,The surface reflectivity of uncoated visible lenses(Refractive index=1.5) is about 4%.

Click on the link to see how to calculate reflectivity

b) AR/AR@400-700nm,Tavg>99.4%

c) AR/AR@450-650nm,Tavg>99.6%

d) AR/AR@400-1000nm,Tavg>98.5%

e) We can also customize high damage threshold antireflective coatings

Round Achromatic Doublet Lens Optical Glass Doublets Cemented Lenses 1

Optical Properties of acromatic lens

Material Optical glass
AR Coating Range 400-700nm or customized
Reflectance over
AR Coating Range @ 0° AOI

Ravg<0.5%

Diameter Tolerance +0.0/-0.1 mm
Thickness Tolerance ±0.1 mm
Focal Length Tolerance ±2%
Surface Quality 40/20 Scratch-Dig
Surface Flatness
(Plano Side)
λ/2 at 633nm
Spherical Surface Powerc
(Convex Side)
1.5λ at 633nm
Surface Irregularity
(Peak to Valley)
λ/2 at 633nm
Centration <3 arcmin
Clear Aperture >Ø10.16 mm (Ø1/2" Lenses)
>Ø20.32 mm (Ø1" Lenses)
Design Wavelength 546nm



Lens Grinding

Round Achromatic Doublet Lens Optical Glass Doublets Cemented Lenses 2

Lens High Speed Polishing

Round Achromatic Doublet Lens Optical Glass Doublets Cemented Lenses 3

Optical Coating

Round Achromatic Doublet Lens Optical Glass Doublets Cemented Lenses 4
