Circular Optical Plano Concave Mirror With Silver Coating , 4-300mm Diameter Range

Basic Information
Place of Origin: Wuhan,China
Brand Name: Wuhan Siwer Optics
Minimum Order Quantity: 10 pieces
Price: 2-120USD/piece
Packaging Details: 1.Tissue paper.plastic foam packaging film And hard carton box with quakeproof filler
Delivery Time: 4-5 weeks
Supply Ability: 20000 pieces/month
Detail Information
Material: Optical Glass,BK7,SF,etc. Type: Plano Concave
Diameter Range: 4-300mm Demension Tolerance: +/-0.1mm
Surface Quality: 40/20 Surface Accuracy: Lambda/4 In 25.4mm
Centration: 3 Arc Min Standard Coating: Silver Coating(HR Coating)
Usage: Optical System
High Light:

pcv lens


plano concave mirror

Product Description

Optical Plano Concave Lens

Plano-Concave Lenses are ideal for beam expansion, light projection, or for expanding an optical system’s focal length. Plano-Concave Lenses, which have one concave surface, are Optical Lenses with negative focal lengths. PCV Lenses should be oriented with the plano, or flat, surface towards the desired focal plane. PCV Lenses are ideal for use in a range of applications or industries.

  • Wavelength Range of 350-2200nm
  • Precision Diameter and Centration Tolerances Allow for Easy OEM Integration
  • Wide Variety of Diameters, Focal Lengths, and Coatings
  • Anti-Reflection Coating Options: MgF2, VIS 0°, VIS-NIR, NIR I, and NIR II

Plano-Concave (PCV) lenses have one flat and one inward curved surface. PCV lenses have a negative focal length and are used for image reduction or to spread light.


Optical AR Coating

a) Uncoated,The surface reflectivity of uncoated visible lenses(Refractive index=1.5) is about 4%.

b) AR/AR@400-700nm,Tavg>99.4%

c) AR/AR@450-650nm,Tavg>99.6%

d) AR/AR@400-1000nm,Tavg>98.5%

e) We can also customize high damage threshold antireflective coatings


Circular Optical Plano Concave Mirror With Silver Coating , 4-300mm Diameter Range 0



Production Line

Circular Optical Plano Concave Mirror With Silver Coating , 4-300mm Diameter Range 1

Optical Properties of Plano optical Lens

Material Optical glass
AR Coating Range 400-700nm or customized
Reflectance over
AR Coating Range @ 0° AOI
Diameter Tolerance +0.0/-0.1 mm
Thickness Tolerance ±0.1 mm
Focal Length Tolerance ±2%
Surface Quality 40/20 Scratch-Dig
Surface Flatness
(Plano Side)
λ/2 at 633nm
Spherical Surface Powerc
(Convex Side)
1.5λ at 633nm
Surface Irregularity
(Peak to Valley)
λ/2 at 633nm
Centration <3 arcmin
Clear Aperture >Ø10.16 mm (Ø1/2" Lenses)
>Ø20.32 mm (Ø1" Lenses)
Design Wavelength 546nm
