Place of Origin: | Wuhan,China |
---|---|
Brand Name: | Wuhan Siwer Optics |
Minimum Order Quantity: | 10 pieces |
Price: | 50-300USD/piece |
Packaging Details: | 1.Tissue paper. 2.Plastic foam packaging film. 3.Hard carton box with quakeproof filler |
Delivery Time: | 4-6 weeks |
Payment Terms: | T/T, Western Union |
Supply Ability: | 2000 pieces/month |
Material: | Optical Glass | Size Tolerance: | +/-0.1mm |
---|---|---|---|
Chamfer: | 0.2-0.5mm | Surface Quality: | 40/20 |
Surface Flatness: | Lambda/4 In 25.4mm | Parallelism: | 2 Arc Min |
Size Range: | 2-100mm | Usage: | Optical System |
High Light: | narrow bandpass optical filter,narrow band interference filter |
Available in UV, Visible, and IR Center Wavelengths
10 – 80nm Bandwidths Available
Ideal for Biomedical Applications and Instrumentation Integration
220-399nm, 400-699nm, and 700-1650nm CWL Options Available
Traditional Coated Bandpass Interference Filters are used to selectively transmit a narrow range of wavelengths while blocking all others, and are ideal for a range of biomedical and quantitative chemical applications.
Narror Bandpass interference filters are widely used in instrumentation for a variety of applications including clinical chemistry, environmental testing, colorimetry, elemental and laser line separation, flame photometry, fluorescence and immunoassays. In addition, bandpass interference filters are used to select discrete spectral lines from arc or gas discharge lamps, and to isolate a particular line from Ar, Kr, Nd:YAG, and other lasers. They are often used in conjunction with laser diode modules and LEDs.
Partial stock filter list
Item | Size(mm) | Unit price(USD) |
850nm Narrow band pass filter | Φ4.2*1.1 | 10 |
Φ4.5*0.55 | 10 | |
Φ6*2 | 10 | |
Φ8*0.55 | 4 | |
Φ8*1.1 | 4 | |
Φ10.4*1 | 5 | |
Φ14*1 | 10 | |
Φ15*1.1 | 10 | |
Φ17*0.7 | 14 | |
Φ20*0.55 | 14 | |
Φ23*1.1 | 21 | |
Φ25*0.55 | 14 | |
Φ27*1.2 | 26 | |
Φ29*1.7 | 26 | |
Φ34*1 | 51 | |
Φ37.5*1.2 | 26 | |
4.5*4.5*0.55 | 3 | |
6.2*6.2*0.5 | 3 | |
7*2*1 | 10 | |
8.2*8.2*0.55 | 4 | |
8.5*2*1 | 10 | |
10*10*0.55 | 5 | |
10*7.5*0.55 | 8 | |
14*14*1.1 | 8 | |
14*7*1.1 | 8 | |
16.9*16.9*1 | 21 | |
17*17*0.55 | 21 | |
17.8*17.8*0.55 | 21 | |
15.5*8*1.1 | 21 | |
23.5*15.6*1.1 | 21 | |
27*20*0.6 | 26 | |
30.5*23*0.6 | 26 | |
35*2*1 | 21 | |
37*8.2*0.55 | 14 | |
57*9*1.8 | 21 | |
80*14*1 | 51 | |
86*86*0.55 | 103 | |
8.2*8.2*1 | 7 | |
14*14*1 | 14 | |
Item | Size(mm) | Unit price(USD) |
450nm narrow band pass filter | Φ3.5*1 | 14 |
Φ5*1.5 | 10 | |
Φ6.5*1.7 | 14 | |
Φ8*1.1 | 17 | |
Φ11.5*1.5 | 21 | |
Φ15*1.5 | 21 | |
Φ25*1.5 | 21 | |
Φ30*1.5 | 21 | |
Φ35*1.4 | 48 | |
Φ36*1.5 | 48 | |
Φ39*1.6 | 69 | |
Φ45*1 | 86 | |
Φ50*1.8 | 103 | |
Φ51*1.5 | 103 | |
10*5*1.65 | 17 | |
14*14*1.1 | 21 | |
14*7.5*1.1 | 21 | |
14*8.1*1.1 | 21 | |
16.5*16.5*1.1 | 21 | |
18*18*1.7 | 21 | |
19.5*16.8*1.5 | 21 | |
30*5*1.1 | 21 | |
38*20*1.1 | 34 | |
39*23*2.2 | 48 | |
Item | Size(mm) | Unit price(USD) |
625-665nm band pass filter | 4.8*2.6*1 | 10 |
6*4.6*1 | 3 | |
5*5*1.2 | 10 | |
6.5*6.5*1 | 3 | |
9*9*1 | 3 | |
10*10*1 | 10 | |
6*6*1 | 3 | |
9*9*1 | 3 | |
16*16*1.7 | 14 | |
16.5*16.5*1.1 | 21 | |
25*14*1.1 | 21 | |
30*30*1.7 | 21 | |
Φ6*1 | 3 | |
Φ8*1 | 3 | |
Φ12*1.1 | 12 | |
Φ16*1.1 | 12 | |
Φ20*1.1 | 12 | |
Φ24*1 | 14 | |
Φ25*1.1 | 14 | |
Φ26*1.1 | 14 | |
Φ29*1.2 | 14 | |
Φ30*1.1 | 14 | |
Φ39*1.1 | 34 | |
600-750nm band pass filter | Φ21.5*2.3mm | 21 |
Φ27.5*2.3mm | 21 | |
600-480nm band pass filter | 7.65*7.65*0.7mm | 14 |
420nm-620nm&850nm band pass filter | Φ8*0.55mm | 3 |
10*10*0.55mm | 4 | |
30*30*1.1mm | 7 | |
697nm narrow band pass filter | Φ20*1.75mm | 26 |
400-950nm band pass filter | 40*10*1.1mm | 21 |
820-1100nm band pass filter | 40*10*1.6mm | 21 |
970nm narrow bandpass filter | Φ19*0.7mm | 21 |
Item | Size(mm) | Unit price(USD) |
520nm narrow bandpass filter | Φ14*1.1mm | 21 |
Φ16.5*1.6mm | 21 | |
Φ24*1.1mm | 21 | |
Φ25*1.7mm | 21 | |
Φ30*1.1mm | 26 | |
Φ39*1.1mm | 71 | |
8*8*1.1mm | 18 | |
20*20*1.2mm | 21 | |
Item | Size(mm) | Unit price(USD) |
689-725nm bandpass filter | Φ39*1.8mm | 49 |
563nm narrow bandpass filter | 80*20*1mm | 49 |
680-760 bandpass filter | Φ29.5*2.2mm | 21 |
Φ12*1.8mm | 18 | |
Φ7*2.3mm | 14 | |
80*8.5*1.7mm | 26 | |
Item | Size(mm) | Unit price(USD) |
760-850nm bandpass filter | Φ8*1.2mm | 14 |
14*14*1.1 | 21 | |
Item | Size(mm) | Unit price(USD) |
940nm narrow bandpass filter | Φ8*0.7mm | 7 |
Φ10*0.55mm | 14 | |
Φ12*1.1mm | 14 | |
Φ15*1mm | 21 | |
Φ22*1.1mm | 21 | |
Φ25*1.1mm | 26 | |
Φ28*1.1mm | 26 | |
Φ36*1.3mm | 71 | |
Φ39*1.5mm | 71 | |
10*10*0.7mm | 7 | |
14*6*0.6mm | 18 | |
14*14*0.6mm | 21 | |
500-550nm bandpass filter | 4.8*2.6*0.7mm | 7 |
6*6*1.1mm | 14 | |
8*8*1.65mm | 14 | |
11.3*1.6*1.55mm | 14 | |
70*20*2.5mm | 35 | |
Φ20*2mm | 21 | |
Φ27*1.45mm | 21 | |
Φ36*2.45mm | 26 | |
450-1100nm longpass filter | Φ25*1.1mm | 21 |
Φ35*1.3mm | 49 | |
420-480nm bandpass filter | 6*6*1.7mm | 14 |
18*18*1.6mm | 18 | |
Φ30*1.46mm | 21 | |
80*39*2.3mm | 71 | |
80*10*1.65mm | 18 | |
Φ8*1.7mm | 14 | |
10*10*2mm | 18 | |
Φ12.5*1.5mm | 18 | |
Φ35*1.6mm | 35 |
